TMT 400LLS Automatic Gate

$1,025.00$1,864.00 incl GST

TMT 400LLS Heavy Duty Model
Swing Gates up to 450kg**

auto gates

TMT 400LLS Auto Gates

Featuring a die cast aluminium motor cover that provides resistance to critical environmental factors. The 400LLS is one of the most robust auto gates on the market featuring auto closing, soft stopping, self learning and party mode feature.

Will this system work if my gate swings outwards?
YES, the TMT system can be setup for an inward swinging or outward swinging gate and still allow you to have the actuator arm located on the inside of the property.
If this setup is preferred make sure to order the ‘TMT Push to Open Bracket’

The TMT 400LLS Auto Gates are
suited for medium to heavy duty swing gates

The TMT 400LLS automatic gate opener brings added convenience to opening your gate from the comfort of your car. Say goodbye to the hassle of manually opening and closing your gate because now you can do it with ease from your home or vehicle with a quick motion.

In addition, the TMT 400LLS gate opener is a highly adaptable system. It works seamlessly with gates that swing inwards or outwards, whether they are found on residential or farm properties. This system caters to your specific needs. Another feature is its sleek actuator arms, which blend perfectly with residential gates. However, this gate opener is not only about style; it also delivers exceptional performance with its silent yet powerful motors. These motors in fact play a crucial role in its operation. Experience the smooth and quiet functioning of your gate while enjoying the convenience of automated control.

Auto Gate Features

  • High Quality die cast aluminium motor cover
  • Metal Worm driven actuator
  • Auto Close function available up to 300 seconds
  • Max gate length 5mtrs
  • 24v Solar or Electric
  • Easy access to limit switch for adjustments
  • Residential application
  • Manual release on top for easy operation
  • Inbuilt obstruction sensor feature
  • Soft stopping & self learning

Auto Gates Specifications

  • Max Gate Length: 5mtrs
  • Max Gate Weight: 450kgs
  • Gear Type: Worm gear
  • Power Supply: 110-240VAC (50-60Hz)
  • Motor Power Supply: 24VDC
  • Peak Thrust: 4500N
  • Enclosure Dimensions(mm): 1040*123*124
  • Manual Release: Key
  • 2 limit options: limits or overcurrent
electric gate openers

Solar Kit Inclusions

  • Actuator arm/s
  • Control Box
  • Control Board
  • 2 x remotes (with 2 free visor/holders)
  • Post/gate brackets and gate stop
  • 2 x Release keys
  • Warning sign
  • 24Volt 40watt solar panel with mounting bracket & 10mtrs cable
  • 20A PWM Solar Regulator
  • 2 x 12v 14ah deep cycle batteries
  • 1 x Battery box with steel mounting bracket
  • Supporting wires
  • Single kit – 2mtrs prewired 7 core arm cable
  • Double kit – 1 @ 2mtrs and 1 @ 12mtrs prewired 7 core arm cable
solar gate openers

Electric Kit Inclusions

  • Actuator arm/s
  • Control Box
  • Control Board
  • 2 x remotes (with 2 free visor/holders)
  • Post/gate brackets and gate stop
  • 2 x Release keys
  • Warning sign
  • 1 x 24Volt Outdoor Transformer
    (low voltage cable & connector not supplied)
  • Single kit – 2mtrs prewired 7 core arm cable
  • Double kit – 1 @ 2mtrs and 1 @ 12mtrs prewired 7 core arm cable
electric gate openers
